🔧 Technical Specifications
Electrical Characteristics
- Power Consumption: 100W
- Input Voltage: 12V DC
- Power Factor: >0.95
- Frequency: 50/60 Hz
- Current Draw: Approx. 0.9A at 120V equivalent
- Voltage Tolerance: ±10%
💡 Optical Performance
- Luminous Flux: 10,000–12,000 lumens
- Color Temperature: 5000K (Daylight White)
- Color Rendering Index (CRI): >80
- Beam Angle: Wide 120° coverage
- Light Distribution: Uniform and glare-free
📦 Physical Characteristics
- Dimensions: 240 × 190 × 55 mm
- Weight: 2–2.5 kg
- Housing: Die-cast aluminum
- Lens: 4mm thick tempered glass
- Mounting: Adjustable 360° rotatable bracket
- Finish: Corrosion-resistant powder coating
🌧 Environmental Protection
- IP Rating: IP65 (dust-tight and resistant to water jets from any direction)
- Operating Temperature: -20°C to +50°C
- Humidity Resistance: Up to 90% non-condensing
⚙️ Performance Characteristics
- Luminous Efficiency: >100 lm/W
- Lifespan: 50,000 hours
- Startup: Instant full brightness
- Dimming: Compatible with 0–10V systems
- Surge Protection: Up to 4kV
🔥 Advanced Features
- Thermal Management: Aluminum heat sink for efficient cooling and extended LED lifespan
- Optical Lens Technology: Precision lens minimizes scatter and improves beam uniformity
- EMC Compliance: Low electromagnetic interference, meets international standards
🛠 Installation & Mounting
- Versatile Mounting: Wall, pole, or ground installation
- Adjustable Bracket: Allows precise angle and targeted illumination
- Easy Setup: Simple wiring, minimal mounting hardware required
🏟 Ideal Applications
- Commercial: Parking lots, building facades, signage illumination
- Industrial: Warehouses, manufacturing facilities, loading docks
- Security & Safety: Perimeter lighting, construction sites, storage areas
- Recreational: Sports fields, outdoor events, landscaping
🌱 Advantages
- Energy Efficient: Reduces electricity costs
- Durable: Robust construction for long-term outdoor use
- Eco-Friendly: Mercury-free, no UV or IR radiation, low carbon footprint
- Low Maintenance: Long lifespan and minimal replacement costs
- Safe & Reliable: No flicker, instant-on technology, superior visibility
✔ Certifications
- CE Certified
- RoHS Compliant
- EMC Tested
- LM-80 & TM-21 Standards
🛡 Warranty & Support
- Warranty: 5 years
- Manufacturer Support: Comprehensive and responsive customer service
